YEMG298WBAM 2.4/5.8GHz panel antenna Frequency band: 2400–2483MHz, 5150–5850MHz Dimensions: 270mm x 270mm x 43.41mm 1.4kg RoHS compliant Electrical: Gain: 2.4GHz 14dBi, 5.8GHz 17dBi VSWR: ≤1.5 3dB beam width: 2.4GHz 45°(H)/45°(E)…
YEMG493KPAM 4 x 4 MIMO panel antenna Frequency band: 3300–4200MHz Dimensions: 210mm x 210mm x 48mm RoHS and REACH compliant Electrical: HBW, Ave., degrees: 62, 60 VBW, Ave., degrees: 33.…
YEMJ294JPAM omni ceiling antenna Frequency band: 617–5950MHz Dimensions: Φ 256mm x 18mm RoHS and REACH compliant Electrical: Horizontal beamwidth, degrees: 360 Gain, dBi: 3.4, 3.8, 4.0, 4.5, 6.5, 5.5 VSWR:…
YECT001W1WM 4G terminal mount rubber monopole external antenna Frequency band: 698–960MHz, 1710–2690MHz Dimensions: 52.6mm x 18.6mm x 9mm Efficiency: up to 68.9% RoHS and REACH compliant IP rating: IP54 The…
YEBT001WFWM Wi-Fi & V2X terminal mount rubber monopole antenna Frequency band – Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz Frequency band – V2X: 5850–5925MHz Dimensions: 52.6mm x 18.6mm x 9mm Efficiency: up to…
YEBT001WFXM Wi-Fi & V2X terminal mount rubber monopole external antenna Frequency band – Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz Frequency band – V2X: 5850–5925MHz Dimensions: Φ 9mm x 54.9mm Efficiency: up to…
YEBT062W1AM Wi-Fi & V2X terminal mount rubber monopole external antenna Frequency band – Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz Frequency band – V2X: 5850–5925MHz Dimensions: 52.6mm x 18.6mm x 9mm Efficiency: up…
YENT060W1AM LPWA/ISM screw mount stubby monopole external antenna Frequency band: 863–930MHz Dimensions: Φ 9.4mm x 34.7mm Efficiency: up to 62.9% RoHS and REACH compliant The YENT060W1AM is an ISM antenna…
YECT005W1AM 5G terminal mount rubber dipole external antenna Frequency band: 600–6000MHz Dimensions: Ф 13mm x 196.2mm Efficiency: up to 66.01% RoHS compliant The YECT005W1AM is a 5G antenna measuring Ф…
YEBT064W1AM Wi-Fi terminal mount rubber monopole external antenna Frequency band: 2400–2500MHz, 5150–5850MHz, and 5925–7125MHz Dimensions: 135mm x 15.6mm x 13mm Efficiency: up to 75% (EVB) RoHS and REACH compliant IP…
