Quectel New Product Release – YEMA300QXA

YEMA300QXA LTE/Wi-Fi/GNSS combo antenna

To meet customers’ requirements for the high performance, high integration, and integrated appearance of their products, Quectel provides a combined antenna box series. These antenna boxes can integrate a variety of antennas, such as 5G, 4G, GNSS, Wi-Fi antennas, to achieve communication functions of 5G MIMO, 4G, GNSS, and Wi-Fi. These antenna boxes can be mounted on the surface of devices via screw, adhesive or other methods, supports multiple connector types and cable lengths. This is a more flexible and reliable high-performance antenna solution for outdoor applications.

  • Frequency – LTE: 700-960MHz, 1700-2700MHz
  • Frequency – Wi-Fi/BT: 2400-2500MHz, 5150-5850MHz
  • Frequency – GNSS: 1559-1606MHz
  • Maximum efficiency: 50%
  • GNSS LNA gain: 18 ±3 dB
  • Dimensions: 143.73mm × 51.33mm × 15mm
  • Cable length: 1028±28mm
  • RoHS compliant
  • IP rating: IP67

Key features

  • Optimized for LTE and Wi-Fi/BT networks
  • Adhesive mount
  • SMA male connectors
  • Durable PC casing
