Quectel New Product Release – EG915Q
LTE Cat 1 bis EG915Q series
Quectel’s EG915Q series is a series of LTE Cat 1 bis modules optimized specially for M2M and IoT applications. Adopting the 3GPP Rel-14 LTE technology, it delivers maximum data rates up to 10Mbps downlink and 5Mbps uplink. Designed in a compact and unified form factor, EG915Q series is compatible with Quectel LPWA BG95 series/BG96/ BC95-G modules and LTE Standard EG91/ EG95 series modules.
The EG915Q series contains 3 variants: EG915Q-NA, EG915Q-JP and EG915Q-AF. A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB serial drivers for Windows 8/ 8.1/ 10/ 11, Linux, and Android) extend the applicability of the modules to a wide range of M2M and IoT applications, such as asset management, commercial telematics, payment, RMAC (remote monitoring and control applications), smart safety and automation, smart metering and smart grid.
- LTE Cat 1 bis module
- LGA form factor
- 23.6mm × 19.9mm × 2.4mm
- 2.3g
- Max. data rates of 10Mbps DL and 5Mbps UL
- Extended temperature range -40°C to +85°C
Key features
- LTE-FDD coverage
- Supports DFOTA
- Main antenna and GNSS antenna (optional)
- Compact size
- Supports Wi-Fi Scan
